20
Product Version 1.0 | Revision D | Released 2022-06-20
UNIVERSAL BRACKET ATTACHMENT
LABEL IS FACING AWAY FROM THE CENTER OF THE FIXTURE. BOLTS TO MOUNTING SURFACE WILL USE THIS
SLOT.
M10 Countersunk Bolts
POI Universal Bracket
Fixture
Using a bolt through this slot,
the fixture will rotate around its
center point, always use 2 bolts
with washers.
Using a bolt through this slot,
the fixture will rotate around its
center point, always use 2 bolts
with washers.
To Next Page
