SGM Q8 - RDM Functions and Sensors

32
Product Version 1.0 | Revision D | Released 2022-06-20
SUPPORTED RDM FUNCTIONS
The Q-8 features are supported via various RDM functions.
RDM (Remote Device Management) is a protocol enhancement to USITT DMX512 that allows bi-directional commu-
nication between the fixtures and the controller over a standard DMX line. This protocol will allow configuration, sta-
tus monitoring and management.
You will need an RDM controller to get control over the supported parameters. See the tables below for supported
RDM functions.
PLEASE NOTE! THE RDM CONTROLLER COMMUNICATES WITH THE FIXTURES TO SHOW ONLY THE AVAILABLE
SENSORS FOR THIS FIXTURE. THE TABLE IS SUBJECT TO CHANGE WITHOUT NOTICE.
SENSORS
RDM enables various sensor readouts for remote device monitoring. See the table below for sensors and sensor types.
PLEASE NOTE: THE RDM CONTROLLER COMMUNICATES WITH THE FIXTURES TO SHOW ONLY THE AVAILABLE
OPTIONS FOR EACH RDM FUNCTION. THE TABLE IS SUBJECT TO CHANGE WITHOUT NOTICE.
RDM
PID ACTIONS
ALLOWED
NAME
0x0082 - Device Label
0x0081 - Manufacturer Label
0x00E0 - DMX Personality
0x00E1 - DMX Personality description
0x0200 - Sensor Definition
0x0201 - Sensor Value
0x0080 - Device Model Description
0x0400 - Device Hours
0x0051 - Parameter Description
0x0501 - Display Level
0x0500 - Display Invert
0x0090 - Factory Defaults
PID ACTIONS
ALLOWED
NAME
0x1001 - Reset Device
0x0120 - Slot info
0x0121 - Slot Description
0x0122 - Default Slot Value
0x8626 SET CRMX Log Off
0x8060 GET Serial Nr.
0x8632 GET/SET SMPS Calibration
0x8625 GET / SET FAN 0=AUTO 1=LOW
2=HIGH 3=FULL
0x8634 GET/SET 0=HOLD 1=LOW
2=HIGH 3=Q COLOR
0x8637 GET/SET CRMX Bridge Mode
NAME SENSOR TYPE
Mainboard Temperature
RGB Left Temperature
RGB Right Temperature
Strobe Left Bottom Temperature
Strobe Right Bottom Temperature
Strobe Left Top Temperature
Strobe Right Top Temperature
Humidity Base Other
Humidity Head Other
NAME SENSOR TYPE
Wireless Signal Strength Other
Wireless Paired Other
Voltage 50 V Voltage
Voltage 16 V Voltage
RGBW PWM Other
Fixture Derating Other
Base Temperature
