SGM Q8 - Fixture Dimensions; Standard Version Dimensions

2
Product Version 1.0 | Revision D | Released 2022-06-20
DIMENSIONS
STANDARD VERSION
All dimensions in millimeters and inches. Drawing not to scale
This manual covers installation, use, and maintenance of the SGM Q Series. A digital version is available at
www.sgmlight.com or upon request via support@sgmlight.com. The information in this document is subject
to change without notice. SGM and all afliated companies disclaim liability for any injury, damage, direct
or indirect loss, consequential or economic loss, or any other loss occasioned by the use of, inability to use, or
reliance on the information contained in this manual. The SGM logo, the SGM name, and all other trade-
marks in this document perwtaining to SGM services or SGM products are trademarks owned or licensed by
SGM, its afliates, and subsidiaries. This edition applies to rmware version 2.23 or later.
English edition © 2022 SGM Light A/S
®
.
401mm
15,77in
468mm
18,41in
150mm
5,91in
388mm
15,28in
520mm
20,46in
81mm
3,19in
200mm
7,87in
440mm
17,32in
111mm
4,37in
150mm
5,91in
320mm
12,60in
220°
220mm
8,66in
166mm
6,55in
