AR-5726/5731 SIMULATION 6 - 24
Operation/procedure
1. Select an item with 10-key, and press [START] key.
2. Enter the setting value, and press [START] key.
Operation/procedure
Used to display the process control correction information.
Operation/procedure
The following data are displayed.
* The value before entry of SIM is displayed. (It is not revised in real
time.)
If sim entry is just after power turned on, the display value is all 0.
Operation/procedure
Sets the toner density control correction value of the traveling distance
count.
Operation/procedure
The following data are displayed. (The displayed value is the previous
print correction value.)
TARGET = DEV REF+(LIFE-50)+(TH-50)
Developer adjustment value 128, life correction 60 (developer adjust-
ment value plus 10), environment correction 45 (5 subtraction correc-
tion), rapid toner supply correction = 128+(60-50)+(45-50) = 133.)
Item Content Default
1 PR_LIFE_ADJUST
DV count correction Disable/
Enable
(0: Disable, 1: Enable)
1
2 TN_LIFE_ADJUST
Life of toner control DV
correction Disable/Enable
(0: Disable, 1: Enable)
1
3 RATE_ADJUST
Printing rate correction
Disable/Enable
(0: Disable, 1: Enable)
1
4 TONER_ADJUST
Toner unconditionally supply
correction Disable/Enable
(0: Disable, 1: Enable)
1
44-9
Purpose
Adjustment/Setup/Operation data output/Check
(Display/Print)
Function
(Purpose)
Used to display the process control correction
information.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Item Operation
44-14
Purpose
Adjustment/Setup/Operation data output/Check
(Display/Print)
Function
(Purpose)
Used to display the environment (temperature,
humidity) correction information.
Item Operation
TH AREA Current environment area
TMP DATA Detection temperature of sensor (C°)
HUD DATA Detection humidity of sensor (%)
44-16
Purpose Setting
Function
(Purpose)
Used to set the toner density control correction value.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Item Operation
Item
Setting
range
Default
1 0 - 93000 (31-sheet model) 1-99 45
2 93001 - 186000 (31-sheet model) 1-99 45
3 186001 - 279000 (31-sheet model) 1-99 45
4 279001 - 372000 (31-sheet model) 1-99 45
5 372001 - 465000 (31-sheet model) 1-99 45
6 465001 - 857313 (31-sheet model) 1-99 45
7 857314 - 1714625 (31-sheet model) 1-99 45
8 1714626 - 2571938 (31-sheet model) 1-99 45
9 2571939 - 3429250 (31-sheet model) 1-99 45
10 3429251 - 4286563 (31-sheet model) 1-99 45
11 4286564 - 5143875 (31-sheet model) 1-99 45
12 5143876 - 6001188 (31-sheet model) 1-99 45
13 6001189 - 6858500 (31-sheet model) 1-99 45
14 6858501 - 7715813 (31-sheet model) 1-99 45
15 7715814 - 8573125 (31-sheet model) 1-99 45
16 8573126 - 9430438 (31-sheet model) 1-99 45
17 9430439 - 10287750 (31-sheet model) 1-99 45
18 10287751 - 11145063 (31-sheet model) 1-99 45
19 11145064 - 12002375 (31-sheet model) 1-99 45
20 12002376 - (31-sheet model) 1-99 45
21 0 - 93000 (26-sheet model) 1-99 45
22 93001 - 186000 (26-sheet model) 1-99 45
23 186001 - 279000 (26-sheet model) 1-99 45
24 279001 - 372000 (26-sheet model) 1-99 45
25 372001 - 465000 (26-sheet model) 1-99 45
26 465001 - 857313 (26-sheet model) 1-99 45
27 857314 - 1714625 (26-sheet model) 1-99 45
28 1714626 - 2571938 (26-sheet model) 1-99 45
29 2571939 - 3429250 (26-sheet model) 1-99 45
30 3429251 - 4286563 (26-sheet model) 1-99 45
31 4286564 - 5143875 (26-sheet model) 1-99 45
32 5143876 - 6001188 (26-sheet model) 1-99 45
33 6001189 - 6858500 (26-sheet model) 1-99 45
34 6858501 - 7715813 (26-sheet model) 1-99 45
35 7715814 - 8573125 (26-sheet model) 1-99 45
36 8573126 - 9430438 (26-sheet model) 1-99 45
37 9430439 - 10287750 (26-sheet model) 1-99 45
38 10287751 - 11145063 (26-sheet model) 1-99 45
39 11145064 - 12002375 (26-sheet model) 1-99 45
40 12002376 - (26-sheet model) 1-99 45
44-17
Purpose
Adjustment/Setup/Operation data output/Check
(Display/Print)
Function
(Purpose)
Used to display the toner density control reference
value.
Section
Image process
(Photoconductor/Developing/Transfer/Cleaning)
Item Operation
TARGET Toner concentration control reference value
DEV REF Developer adjustment value
LIFE Toner container life correction value (SIM 44-16)
TH Toner container environment correction value
Item
Setting
range
Default
