１ OUTLINE
ＭＵＸ-１００ SERVICE MANUAL １ - ９
Fig. 1-2 X-ray reference axis and focal spot position (front and upper view)
Fig. 1-3 X-ray reference axis and focal spot position (Side view)
View from this side
Refer to Fig.1-3
4-M6 deep12
(P.C.D. φ92)
Focus *1
Reference axis
126 126
φ134
Unit: mm
*1: A hollow on the housing surface
indicates a position of focus
Focus
Reference axis
85
40
M45
Unit : mm
56
