６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - ８
６-２ Battery････････････････････････････････････････････････････････････････････････････････････････
６-２-１ Battery specifications
By one-time charging, the system offers about 60 sets of below mentioned cycle.
1. Traveling 100m on the hard and straight floor
2. Arm positioning with collimator lamp and one exposure with 4 mAs at 100kV with FPD (DR system
CXDI-50G)
3.
Confirmation of the image with DR system and shut down
The number of possible sets of exposure/traveling cycle is about 60% if you compare
with MUX-100/100H because of power consumption by DR system.
６-２-２ Replacement of battery
Parts Number of the battery is 074-71014-01 (Battery,PX12090). 20 pieces are needed
when replacing batteries.
When replacing the batteries, make sure to place the unit on the flat floor.
Otherwise, the unit may fall down.
Do not wear metallic accessories such as the bracelet, hanging jewelrys, and
clocks during the battery exchange work. It is very dangerous when coming in
contact between terminals of the battery.
Pay attention to polarity of +/- when arranging the battery in the battery unit. Do
not short-circuit and contact between terminals.
The battery with a different kind, type, manufacture and residual quantity should
not exist together. The device will not work properly.
(1) All 20 batteries should be replaced with new 20 batteries.
(2) 10 batteries in plus side (Battery ASSY BAT1,BAT2) should be with same
date of manufacture.
(3) 10 batteries in minus side (Battery ASSY BAT3,BAT4) should be with same
date of manufacture.
(4) Difference date of manufacture between plus side 10 batteries and minus
side 10 batteries should be less than one month.
Date of manufacture is stamped on top of the battery.
An example of stamp is as follows.
001231## … Dec.31.2000 (## is alphabet or number which bear no relation to
date of manufacture.)
WARNING
WARNING
WARNING
CAUTION
