１ OUTLINE
ＭＵＸ-１００ SERVICE MANUAL １ - １０
１-４ Name of Each Part ･････････････････････････････････････････････････････････････････････････････
Arm section:
Holds the tube section. It
can slide vertically on the
support stand and the arm
itself can stretch in the
horizontal direction.
X-ray tube unit:
The combination of X-ray tube
and collimator can turn around
the axis of X-ray focus. This
makes positioning and
adjustment of the irradiation
field and small movement of
the unit.
Hand switch:
The switch to make X-ray
exposures
Support Stand:
Holds the tube section
and arm. It can turns
itself.
Key switch:
Turns on/off power for the unit
with this ke
o
eration.
Battery checker:
Indicates remaining charge of the
battery.
Emergency stop switch:
Used to stop the motor in the
event of an emergency.
Running handle:
The handle to drive the unit
.
X-ray control panel:
Refer to Operation
Manual
To Next Page
