６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - １
６-１
How to Remove Covers
････････････････････････････････････････････････････････････････････････････
CAUTION Make sure to set to OFF the breaker before removing the covers. Otherwise, you may get electrical
shock.
６-１-１ Name and position of each cover
There is a sequence of opening/closing the covers as shown in Fig. 4.
For example, to remove the top cover, the side cover must be removed first.
Fig. 6-1 Name of each cover and layout of the covers
Top cover
Side cover
Arm joint section
Cable cover
Front cover
To Next Page
