ＭＵＸ-１００ SERVICE MANUAL １ - ２
１-２ Specifications ･･････････････････････････････････････････････････････････････････････････････････
MUX-100D MUX-100DJ
Use environment
Atmospheric pressure
700～1060hPa
Ambient temperature
10～35℃
Relative humidity
30～75%
Common specifications
Total width 580mm
Total length 1250mm
Height of support stand 1930mm 1780mm
Weight
39４kg (with imaging unit)
Maximum running speed
5±0.5km/h(this may vary depending on the floor condition.)
Imaging unit storage 1 Imaging unit and 1Gid
Focus height
600～2010mm 600～1860mm
Arm length
635～1200mm
Support stand rotation range
±270deg min.
Tube rotation angle
360deg
Tube rotation around tube axis
Forward: 90 deg min.; Backward: 20 deg min.
Minimum distances between Focal
Spot and Image Receptor
312mm
Power supply
Supply voltage Built-in battery
For battery drive:
Battery type
Shielded lead storage battery (12 V×20 cells)
Rating of power supply
1kVA
Supply voltage Single phase AC 100,110,120,200,220,230,240V
Supply Impedance
Single phase AC 100,110,120 V : No more than 1.0Ω
Single phase AC 200,220,230,240 V : No more than 4.0Ω
For battery charge:
Supply frequency 50/60Hz
Power cable length 4m
