１ OUTLINE
ＭＵＸ-１００ SERVICE MANUAL １ - ３
MUX-100D MUX-100DJ
High-voltage generator
Nominal electric power
12.5kW (100kV、125mA、0.1s)
（The product of the current allowed to flow for 0.1 seconds at a tube
voltage of 100 kV and tube voltage）
The nominal maximum tube voltage and
the maximum tube current allowed to flow
at the nominal maximum tube voltage
125kV、100mA
The maximum tube current and the
maximum tube
voltage that allows the maximum tube
current to flow
160mA、 80kV
The combination of the tube voltage and
tube current that output the maximum
electrical power
125kV、100mA
100kV、125mA
80kV、160mA
The minimum value of the current time
product
0.32mAs
The maximum value of the current time
product
320mAs 320mAs
Ratings
The minimum value of nominal irradiation
time
3.2ms
40～90kV 0.32～320mAs 0.32～320mAs
91～100kV 0.32～280mAs 0.32～280mAs
101～110kV 0.32～250mAs 0.32～250mAs
111～120kV 0.32～220mAs 0.32～220mAs
The current time product
that can be set with the
X-ray tube voltage
121～125kV 0.32～200mAs 0.32～200mAs
Range of the setting:
40～125kV、in 1-kV increments
Setting and display of
tube voltage for
exposure
Display: Digital display
Accuracy X-ray tube voltage Less than 10%
Range of the setting:
0.32， 0.36， 0.40， 0.45， 0.50， 0.56， 0.63， 0.71， 0.80， 0.90，
1.0，1.1， 1.2， 1.4， 1.6， 1.8， 2.0， 2.2， 2.5， 2.8， 3.2， 3.6，
4.0， 4.5，5.0， 5.6， 6.3， 7.1， 8.0， 9.0， 10， 11， 12， 14，
16， 18， 20， 22，25，28， 32， 36， 40， 45， 50， 56， 63，
71， 80， 90， 100， 110，125，140, 160， 180， 200， 220， 250，
280， 320mAs
The maximum value is 200 mAs with MUX-100HJE.
Setting and display of
radiographic current time
product.
Display: Digital display
