Shimadzu MOBILE DaRt MUX-100D Series User Manual

４ INSTALLATION AND MAINTENANCE/INSPECTION
ＭＵＸ-１００ SERVICE MANUAL ４ - ２９
P/N Rating Fuse name and location
072-06033-08
100A 600V
(Rapid)
F1 (On INVERTER UNIT-C1 board)
072-01664-34
6.3A 250V
(Slow blow)
F13 (On CONTROL UNIT MUX chassis)
072-01664-15
0.5A 250V
(Slow blow)
F11,F12,F23 (On CONTROL UNIT MUX chassis)
F1 (On MUX CHARGE-04A board)
F6 (On MUX POWER-99 board)
072-01664-26
2A 250V
(Slow blow)
F21,F22 (On CONTROL UNIT MUX chassis)
F1,F2 (On MUX POWER-99 board)
072-01664-33
5A 250V
(Slow blow)
F11,F12,F23 (On CONTROL UNIT MUX chassis)
F3,F7,F8 (On MUX POWER-99 board)
072-01659-83
10A 250V
(Slow blow)
F4,F5 (On MUX POWER-99 board)
072-01665-34
10A 250V
(Slow blow)
F9 (On MUX POWER-99 board)
072-01005
2A 250V
(Slow blow)
F21,F22 (On Link Assy)
Table 4-12 Used Fuse List
