６ ADJUSTMENT/REPLACEMENT OF EACH PART
ＭＵＸ-１００ SERVICE MANUAL ６ - ３２
Adjustment Conditions of Micro switch
（a） If the arm is retracted on the condition that the X-ray tube has been pressed in toward
the support (adequate retraction status), the indicator on the Control Panel located at
the upper part of the main unit should go off. (The OFF status of the indicator should
be retained even if the arm is swung in all four directions.)
（b） If the arm is retracted on the condition that the X-ray tube has been pulled out by
about 5cm from the status described in the above (a) (inadequate retraction status), the
indicator on the Control Panel should be kept turned on.
Operation Check
1. Check that, the panel indication goes off under the retracted status while it remains turned on under the inadequate
retraction status.
2. Allow the traveling under the normal arm retraction status, and check that no problem will occur while the unit is
traveling.
To Next Page
