1.4.2 Signs and Labels
1. Before starting, please refer to
operation section of the manual.
2. Water is used as the heat transfer
medium. The maximum
temperature setting value is
120(248℃
o
F).
This is to indicate motor rotating
direction. When phase reversal
happens, the alarm sounds and
indicator on control panel will
indicate.
Please exchange the place of two of
the electrical wires to solve this
problem.
High voltage! Electrical shock may
happen. Carefulness is required from
the operator.
Attentions!
This is general warnings which
operators should pay attention to.
From mould: connector for
circulating water/oil coming from
mould.
Pump pressure meter: indicating
actual pressure of system.
To mold: connector for circulating
water/ oil to go to mould.
1. To maintain temperature
consistency, cooling water
pressure must be higher than 2
bar at all time, but should never
exceed 5 bar in any case.
2. Clean Y-shape Cooling Water
To Next Page
