Table 2-20：Electrical Components List (STM-910WA 230V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch* 32A YE10323200000
2
Q2 Circuit breakers** 32A YE40603200000
3
- Excitation break away** - YE40023560000
4
K1 K2 Contactors** 220V 50/60Hz YE00601521000
5
K3 Contactors** 220V 50/60Hz YE00602722000
6
F1 Overload relays 3.5~5A YE01160350000
7
F11 Fuse box** 32A 2P YE41032200000
8
- Fuse** 2A YE46002000100
9
S1 Fuse** - -
10
S2 S3 Thermocouple - -
11
S4 Thermocouple - -
12
S5 Hi-lo pressure switch H:5-30bar L:-0.7-6bar YE90083000100
13
PC1 A Circuit board 100~240VAC 50/60Hz YE81100010000
14
Y1~Y3 Solenoid valve** 230VAC 50/60Hz -
15
X1 Solenoid valve** - YE61250040000
16
- Terminal board - YE61253500000
17 - Terminal board - YE61040000000
18 - Terminal board - YE61043500000
19 M1 Motor** 230V 50Hz 0.75kW -
20 EH Heater** 230V 50Hz 9kW -
21
FM Fan* 230V 50/60Hz -
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
