38(107)
2.3.8 Electrical Components List (STM-607WA~1220WA 400V)
Table 2-8：Electrical Components List (STM-607WA 400V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch* 16A YE10021160000
2
Q2 Circuit breakers** 16A YE40601500000
3
- Excitation break away** - YE40023560000
4
K1 K2 Contactors** 220V 50/60Hz YE00601521000
5
K3 Contactors** 220V 50/60Hz YE00601800000
6
F1 Overload relays 1.8~2.5A YE01160180000
7
F11 Fuse box** 32A 2P YE41032200000
8
- Fuse** 2A YE46002000100
9
F12 Fuse** 2A YE41001000000
10
T Transformer 500mA YE70402300800
11
S1 Thermocouple - -
12
S2 S3 Thermocouple - -
13
S4 Overheat protector - -
14
S5 Hi-lo pressure switch H:5-30bar L:-0.7-6bar YE90083000100
15
PC1 A Circuit board 100~240VAC 50/60Hz YE81100010000
16
Y1~Y3
Solenoid valve** 230VAC 50/60Hz
-
17
X1 Terminal board - YE61250040000
18 - Terminal board - YE61253500000
19 M1 Motor** 400V 50Hz 0.5kW -
20 EH1 Heater** 400V 50Hz 6kW -
21
FM Fan* 230V 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
