76(107)
2.3.37 Electrical Components List (STM-3650WA 230V)
Table 2-22：Electrical Components List (STM-3650WA 230V)
序号 符号 名称 规格 物料编号
1 Q1 Circuit-Break 160A YE41161500000
2
- Break Away* 220VAC 50/60Hz YE40121600000
3
K1 Contactors* 220V 50/60Hz YE00602522000
4
K2 K3 K4 Contactors* 220V 50/60Hz YE00503500000
5
K5 Current relay 220V 50/60Hz YE03270700000
6
F1 Overload Relays 16~20A YE01260140000
7
F11 Fuse Box** 32A 2P YE41032200000
8
- Fuse** 2A YE46002000100
9
S1 Thermocouple - -
10
S2 S3 Thermocouple - -
11
S4 Overheat Protector 250V 5(4)A YE21503000000
12
S5 HI-LO pressure switch H:5-30bar L:-0.7-6bar YE90083000100
13
PC1 A Circuit Board* 50/60Hz YE81184300100
14
PC1 A Circuit Board* 50/60Hz YE81184300200
15
H1 Buzzer 230VAC 50Hz YE84003500000
16
Y1 Solenoid Valve** 230V 50/60Hz -
17 X1 Terminal Board - YE61250040000
18 - Terminal Board - YE61253500000
19 - Terminal Board - YE61043500000
20 - Terminal Board - YE61103500000
21
- Terminal Board - YE61353500000
22
M1 Motor** 230V 50/60Hz -
23
EH1 EH2 EH3 HEATER** 230V 50/60Hz -
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
