20(107)
2.2 Assembly Drawing
2.2.1 Assembly Drawing (STM-607W/910W)
Remarks: Please refer to material list 2.2.2 for specific explanation of the Arabic numbers
in parts drawing.
Picture 2-2：Assembly Drawing (STM-607W/910W)
