2.3.17 Electrical Components List (STM-2440W 400V)
Table 2-13：Electrical Components List (STM-2440W 400V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch* 63A YE10636300000
2
Q2 Circuit breakers** 25A YE40606000000
3
- Break away** - YE40023560000
4
K1 Contactors* 220V 50/60Hz YE00601521000
5
K2 K3 Contactors** 220V 50/60Hz YE00602622000
6
F1 Overload relays 5.5~8A YE01160550000
7
T Transformer
IN=400V OUT=230V
500mA
YE70402300800
8
F11 Fuse box** 32A 2P YE41032200000
9
- Fuse** 2A YE46002000100
10
F12 Fuse** 2A YE41001000000
11
S1 Thermocouple - -
12
S2 S3 Thermocouple - -
13
S4 Overheat protector 250V 5(4)A YE21503000000
14
S5 Hi-lo pressure switch H:5-30bar L:-0.7-6bar YE90083000100
15
PC1 Circuit board 100~240VAC 50/60Hz
16
A Control panel -
YE81100010000
17 Y1 Solenoid valve** 230VAC 50/60Hz -
18 X1 Terminal board - YE61250040000
19 - Terminal board - YE61253500000
20 - Terminal board - YE61043500000
21 - Terminal board - YE61160000000
22 - Terminal board - YE61163500000
23
M1 Motor** 400V 50Hz 2.8kW -
24
EH1 EH2 Heater** 400V 50Hz 12W -
25
FM Fan* 230V 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
