56(107)
2.3.21 Electrical Components List (STM-3650W 400V)
Table 2-14：Electrical Components List (STM-3650W 400V)
NO. Symbol Name Specification Part NO.
1
Q1 Circuit break* 90A
YE41109000000
2 - Circuit breake** 220VAC 50/60Hz YE40101600000
3 K1 Break away** 220V 50/60Hz YE00601621000
4 K2~K5 Break away** 220V 50/60Hz YE00602522000
5 F1 Overload relays 7~10A YE01167100000
6 T Transformer*
IN=400V OUT=230V
500mA
YE70402300800
7 F11 Fuse box** 32A 2P YE41032200000
8 - Fuse** 2A YE46002000100
9 F12 Fuse** 2A YE41001000000
10 S1 Thermocouple - -
11 S2 S3 Thermocouple - -
12 S4 Overheat protector 250V 5(4)A YE21503000000
13 S5 Hi-lo pressure switch H:5-30bar L:-0.7-6bar YE90083000100
14 PC1 Circuit board 100~240VAC 50/60Hz
15 A Control panel -
YE81100010000
16
Y1 Solenoid valve** 230V 50/60Hz -
17 X1 Terminal board - YE61250040000
18 - Terminal board - YE61253500000
19 - Terminal board - YE61163500000
20 M1 Motor** 400V 50Hz 4.0kW -
21 EH1~EH4 Heater** 400V 50Hz 9.0kW -
22 FM1 Fan* 230V 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
