27(107)
2.2.8 Parts List (STM-3650W)
Table 2-4：Parts List (STM-3650W)
No.
Name Part No. No.
Name Part No.
1 Black movable castor 3'' YW03000300200
25
Fixing plate for wire
clamp
-
2 Door plate - 26
Outer hexagon screw
M6×16
YW60061600100
3
Door plate aluminum
handle 6609
YW20660900100
27 Spring gasket 6 YW65006000100
4 Control box - 28 Flat gasket 6×18×1 YW66061800000
5 Base plate of control box - 29
Inner hexagon screw
M8×20
YW61082000200
6 Thick head screw M6×20
YW63062000000
30 Flat gasket 8×22×1.5 YW66082200100
7 Rear plate of control box -
31 Spring gasket 8
YW65008000100
8 Filling water pipe 32 TP-400 BM20423000050
9 Return water pipe parts - 33 Flat gasket 8×16×1.5 YW66081600000
10
High pressure pipe - 34
Hexagon screw
M8×30
BM20015000050
11
Low pressure pipe - 35 Hexagon nut M8 YW64080600000
12
Hot water by-pass pipe - 36
Inner hexagon screw
M8×20
YW61082000200
13
Heating tank parts - 37 Spring gasket 8 YW65008000100
14
Cover plate - 38 Flat gasket 8×16×1.5 YW66081600000
15
Pressure gauge pipe - 39 Brake castor 3'' YW03000300000
16
Pressure gauge
(0~10MPa range)
YW85001000100
40 Y type filter 1/2'' YW57010200000
17
Butterfly screw M8×15 YW69081500000
41
Cold water by-pass
pipe
-
18
Lentil-headed screw M510
YW62051000000
42 Drainage pipe parts -
19
Movable arm of the door
plate
- 43
switch
YE90832500000
20
Big hinge CL219-1 YW60061000000
44 Side plate -
21
Fixing plate of door plate - 45 EGO assembly BH90115000050
22
Movable pin of the door
plate
- 46
Heating tank plate
gasket
-
23
M5 Nut YW64000600000
47 Long gear lock YW00000000100
24
Flat gasket 5×13×1.0 YW66051300000
48
Baffle sheet of door
lock
-
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
