Shini STM-W Series User Manual

25(107)
2.2.6 Parts List (STM-2440W)
Table 2-3：Parts List (STM-2440W)
No. Name Part No. No. Name Part No.
1 Movable castor 3” YW03000300200 26 Line clamp fixing plate -
2 Door plate - 27 Big hinge CL219-1 YW60061000000
3
Door plate aluminum
handle 6609
YW20660900100 28
Outer hexagon screw
M6×16
YW60061600100
4 Electrical control box - 29 Spring gasket 6mm YW65006000100
5 Side plate - 30
Flat gasket
6×18×1mm
YW66061800000
6
Base plate of electric
control box
- 31
Inner hexagon screw
M8×20
YW61082000200
7 Thick head screw M6×20 YW63062000000 32 Spring gasket 8mm YW65008000100
8
Rear plate of electric
control box
- 33
Flat gasket
8×22×1.5mm
YW66082200000
9
Water drainage pipe
connector parts
34 PumpTP-280 BM20028000050
10
Copper female
connector(suitable for set
1,2,3,4)
- 35 Pump base plate -
11
Y type filtering water
valve1/2"
YW57010200000 36 Hexagon nut M6 YW64000600300
12 Copper core M13×1/2PT BH12131200010 37
Hexagon head screw
M6×25
YW60062500000
13 Pump flange gasket YR10150000000 38 Brake caster 3" YW03000300000
14
Teflon pipe with connector
3/8"×50CM
YW59385000000 39
High and low pressure
pipe HLP830HME
YE90832500000
15 Filling water pipe - 40 Return pipe parts -
16 Parts of heating tank - 41
Filling pipe connector
parts
-
17 Rack - 42
Cooling water by-pass
pipe
-
18 Cover plate - 43
Hot water by-pass
pipe
-
19 High pressure pipe - 44
Inner hexagon screw
M10×30
YW61103000100
20 High pressure pipe - 45
Thick head screw
M3×6
YW63030600000
21 Pressure gauge pipe - 46 EGO assembly BH90115000050
22
Pressure gauge (Range:
0~1.0MPa)
YW85001000100 47
Flat gasket
10.5×20×2mm
YW66102000100
23 Flat gasket 8×16×1.5mm YW66081600000 48 Spring gasket 10mm YW65010000000
24 Butterfly screw M8×15 YW69081500000 49 long door lock YW00000000100
25
Lentil-headed screw
M5×10
YW62051000000
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
