2.3.29 Electrical Components List (STM-607W~1220W 230V)
Table 2-16：Electrical Components List (STM-607W 230V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch* 25A YE10125250000
2
Q2 Circuit breakers** 25A YE40602500000
3
- Excitation break away** - YE40023560000
4
K1 Contactors** 220V 50/60Hz YE00601521000
5
K2 Contactors** 220V 50/60Hz YE00602522000
6
F1 Overload relays 2.8~4A YE01160280000
7
F11 Fuse box** 32A 2P YE41032200000
8
- Fuse** 2A YE46002000100
9
S1 Fuse** - -
10
S2 S3 Thermocouple - -
11
S4 Thermocouple - -
12
S5 Hi-lo pressure switch H:5-30bar L:-0.7-6bar YE90083000100
13
PC1 Circuit board 100~240VAC 50/60Hz
14
A Control panel -
YE81100010000
15
Y1 Solenoid valve** 230VAC 50/60Hz -
16
X1 Solenoid valve** - YE61250040000
17 - Terminal board - YE61253500000
18 - Terminal board - YE61040000000
19 - Terminal board - YE61043500000
20 M1 Motor** 400V 50Hz 0.5kW -
21
EH Heater** 400V 50Hz 6kW -
22
FM Fan* 230V 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
