Table 2-6：Electrical Components List (STM-910W 400V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch* 25A YE10125250000
2
Q2 Circuit breakers** 25A YE40602500000
3
- Excitation break away** - YE40023560000
4
K1 Contactors** 220V 50/60Hz YE00601521000
5
K2 Contactors** 220V 50/60Hz YE00602522000
6
F1 Overload relays 2.2~3.2A YE01160220000
7
F11 Fuse box** 32A 2P YE41032200000
8
- Fuse** 2A YE46002000100
9
F12 Fuse** 2A YE41001000000
10
T Transformer 500mA YE70402300800
11
S1 Thermocouple - -
12
S2 S3 Thermocouple - -
13
S4 Overheat protector - -
14
S5 Hi-lo pressure switch H:5-30bar L:-0.7-6bar YE90083000100
15
PC1 Circuit board 100~240VAC 50/60Hz
16
A Control panel -
YE81100010000
17
Y1
Solenoid valve** 230VAC 50/60Hz
-
18 X1 Terminal board - YE61250040000
19 - Terminal board - YE61253500000
20 - Terminal board - YE61040000000
21
- Terminal board - YE61043500000
22
M1 Motor** 400V 50Hz 0.75kW -
23
EH1 Heater** 400V 50Hz 9kW -
24
FM Fan* 230V 50/60Hz -
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
To Next Page
