60(107)
2.3.25 Electrical Components List (STM-3650WA 400V)
Table 2-15：Electrical Components List (STM-3650WA 400V)
序号 符号 名称 规格 物料编号
1 Q1 Circuit-Break 90A YE41109200000
2
- Break Away* 220VAC 50/60Hz YE40121600000
3
K1 Contactors* 220V 50/60Hz YE00601621000
4
K2 K3 K4 Contactors* 220V 50/60Hz YE00602722000
5
K5 Current relay 220V 50/60Hz YE03270700000
6
F1 Overload Relays 7-10A YE01167100000
7
T Transformer 500mA YE70402300800
8
F11 Fuse Box** 32A 2P YE41032200000
9
- Fuse** 2A YE46002000100
10
F12 Fuse** 2A YE41001000000
11
S1 Thermocouple - -
12
S2 S3 Thermocouple - -
13
S4 Overheat Protector 250V 5(4)A YE21503000000
14
S5 HI-LO pressure switch H:5-30bar L:-0.7-6bar YE90083000100
15
PC1 A Circuit Board* 50/60Hz YE81184300100
16
PC1 A Circuit Board* 50/60Hz YE81184300200
17 H1 Buzzer 230VAC 50Hz YE84003500000
18 Y1 Solenoid Valve** 230V 50/60Hz -
19 X1 Terminal Board - YE61250040000
20 - Terminal Board - YE61253500000
21
- Terminal Board - YE61163500000
22
M1 Motor** 400V 50Hz -
23
EH1 EH2 EH3 HEATER** 400V 50Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
