Shinko DCL-33A - OUT2 Action with Overlap Band; Overlap Band Control Logic

35
8.6 OUT2 Action (When Setting Overlap Band)
OFF
ON
SV
OFF
ON
Heating
control
Relay
contact
output
Cycle action is performed
according to deviation.
3
+
4
-
12 V DC
3
+
4
-
12/0 V DC
3
+
4
-
0 V DC
3
+
4
-
20 mA DC
3
+
4
-
20 to 4 mA DC
3
+
4
-
4 mA DC
3
4
3
4
3
4
8
+
9
-
OFF/ON
8
+
9
-
OFF
8
+
9
-
ON
OUT1 P-band
OUT2 P-band
Overlap
band
Cooling
control
Control
action
Cycle action is performed
according to deviation.
Changes continuously
according to deviation.
Changes continuously
according to deviation.
Indicator
(OUT)
Green
Indicator
(EVT)
Red
Lit
Unlit
Unlit
Lit
: Turns ON (lit) or OFF (unlit).
: Represents Heating control action.
: Represents Cooling control action.
Non-contact
voltage
output
Direct
current
output
Open
collector
output
