Shure MXW - Microphone Placement Guidelines; Boundary Microphone Placement; Desktop Gooseneck Base (MXW8)

Boundary (MXW6/C, MXW6/O)
The boundary transmitter sits on a table or desk to transmit speech while discreetly blending into any conference environment. Cardioid and omnidirectional
versions are available.
MXW2
MXW6MXW1 MXW8
Microphone Placement
For best low-frequency response and rejection of background noise, place the microphone on a large, flat surface, such as a floor, table, or lectern.
To reduce reverberance, avoid reflective surfaces above or to the side of the microphone, such as beveled sides of pulpits or overhanging shelves.
46 cm
(18 in.)
46 cm
(18 in.)
1 m
(3 ft.)
60 cm
(2 ft.)
MXW6/CMXW6/O
Desktop Gooseneck Base (MXW8)
The gooseneck base is compatible with 5, 10, and 15” Microflex gooseneck microphones.
MXW2
MXW6MXW1 MXW8
Shure IncorporatedMXW
13/722017/05/17
