WARNING
Risk of injury and damage caused by potential equalization currents!
Improper grounding can lead to dangerous equipotential bonding currents, which may
in turn lead to dangerous voltages on metallic surfaces, such as the housing. Electrical
voltage can cause severe injury or death.
■
Work on electrical systems must only be performed by qualified electricians.
■
Follow the notes in the operating instructions.
■
Install the grounding for the product and the system in accordance with national
and regional regulations.
Additional information about laser radiation
The device uses a red light laser diode.
The entire reading window is a laser output aperture.
Figure 1: Laser output aperture in the housing
1
Laser output on side
2
Laser output on front
NOTE
No maintenance is required to ensure compliance with Laser Class 2.
Warning symbol on the device
The laser warning label is affixed on the rear of the device in combination with the type
label.
In addition to other information, the type label also contains the relevant laser output
data.
Figure 2: Laser warning label
Meaning of the laser warning label:
Laser radiation – Never look into the light beam – Laser Class 2
SAFETY INFORMATION 2
8017842/ZOK7/2019-02-01 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x DualPort (PROFINET)
11
Subject to change without notice
