5 Mounting
5.1 Overview of mounting procedure
Selecting and preparing the mounting location.
Mounting the device.
Align device towards object with bar code.
Connect device to data cable (PROFINET) and supply cable.
Adjust the device.
WARNING
Risk of injury due to damage to the device
For reasons of safety, a device which is visibly damaged must not be operated or must
be immediately taken out of operation. Damage includes, for example:
Housing: Cracked or broken
Reading window lens: Cracked or broken
Device with connector: Over-rotation of the connector, cracks, or being torn from
the housing
Device with fixed cable: Damage to the cable outlet or cable itself
5.2 Preparation for mounting
5.2.1 Mounting requirements
NOTICE
Radio interference may occur when the device is used in residential areas!
Only use the device in industrial environments (EN 61000-6-4).
Space requirements
Typical space requirement for device, see type-specific dimensional drawing and
reading field diagram.
The device requires a direct, unimpeded line of sight to the codes being read.
Environmental influences
Comply with technical data, such as the permitted ambient conditions for opera‐
tion of the device (e.g., temperature range, EMC interference emissions, ground
potential), see "Technical data", page 55.
To prevent the formation of condensation, avoid exposing the device to rapid
changes in temperature.
Keep the device out of direct sunlight. The prevents additional external heating
and potential optical dazzle of the device.
Mounting
The device must only be mounted using the pairs of blind tapped holes provided
for this purpose.
Mount the device in a shock- and vibration-insulated manner.
Equipment required
Mounting device (bracket) with sufficient load-bearing capacity and suitable
dimensions for the device.
2 x M5 screws – the maximum screw-in depth in the device is 5 mm from the
housing surface
5 MOUNTING
26
O P E R A T I N G I N S T R U C T I O N S | CLV61x DualPort (PROFINET) 8017842/ZOK7/2019-02-01 | SICK
Subject to change without notice
