12 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/CLV61x_Dual_Port
These operating instructions provides additional technical data if required.
12.1
optical lens system
Table 13: CLV61x Dual Port: technical data for optics
CLV615 CLV618
Working range Long range Long range
Scanning Method Line or grid scanner
1)
, type-dependent, identifier see "Type code",
page 13
Reading window orienta‐
tion
On the front or to the side (light emission at 105° relative to the
longitudinal axis of the device), type-dependent, identifier see
"Type code", page 13
Aperture angle ≤ 50°
Focus Fixed focus
Resolution 0.35 mm ... 0.5 mm 0.35 mm ... 1 mm
Reading areas see "Reading field diagrams", page 58
Scanning frequency 400 Hz to 1,000 Hz
Light source Laser LED, visible red light (λ = 655 nm)
MTTF (laser diode) 40,000 h at 25 °C
Laser class Class 2 according to EN/IEC 60825-1:2014. Identical laser class
for issue EN/IEC 60825-1:2007.
Complies with 21 CFR 1040.10 except for tolerances according to
Laser Notice no. 50 of June 24, 2007.
Laser power P = 1.5 mW maximum, P
< 1.0 mW average
P = 3.2 mW maximum, P
< 1.0 mW average
Laser pulse duration < 300 µs
1)
Grid height approx. 15 mm at a reading distance of 200 mm
12.2 Performance
Table 14: CLV61x Dual Port: technical data for performance
Bar code types Code 39, Code 128, Code 93, Codabar, UPC / GTIN / EAN,
2/5 Interleaved, Pharmacode
Print ratio 2:1 ... 3:1
No. of codes per scan 1 ... 10 (standard decoder)
1 ... 6 (SMART620)
No. of codes per reading
interval
1 to 50 (auto-discriminating)
No. of characters per read‐
ing interval
1)
Max. 50 characters (max. 1,500 characters across all bar codes
per reading interval)
