7 Commissioning
7.1 Overview of the commissioning steps
Commissioning, adjustment, configuration and diagnostics of the device are performed
by default using the SOPAS ET configuration software.
The configuration can differ from this if, for example an across-the-board configuration
of the device is done centrally in the control environment by the PROFINET controller
(e.g PLC) (configuration using modules in the GSD file of the device). At each restart of
the PROFINET, the PROFINET controller overwrites and prioritizes the current device
parameters.
■
Commission device using factory default settings.
■
Connect the PC with the SOPAS-ET configuration software to the device.
■
To optimize the functionality of the device, adjust the device and adapt the config‐
uration as needed. The configuration data are stored and archived as a parameter
set (project file) on the PC as part of a backup concept. On device variants with
the optional memory card, the device also creates a permanent backup of the con‐
figuration data on the card.
■
Test the device for correct functionality in read operation.
NOTE
The procedure for incorporating the device into the PROFINET controller (PLC) and for
central parameterization using the PROFINET controller is described in the supplemen‐
tary information document “Bar code scanner CLV61x Dual Port (PROFINET)” in English
(part no. 8017978) and German (part no. 8017977).
The supplementary information can be found under "Documentation" on the online
product page at:
•
www.sick.com/CLV61x_Dual_Port
7.2 Install and launch the SOPAS ET configuration software
NOTE
The configuration software SOPAS ET, the current system prerequisites for the PC, and
the instructions for downloading can be found online at:
•
www.sick.com/SOPAS_ET
1. Electrically connect a device data interface with a PC that can connect to the Inter‐
net.
2. In accordance with the instructions, download and install the latest version of the
configuration software SOPAS ET, as well as the current device description file
(*.sdd) for the device. In this case, select the “Complete” option as selected by the
installation wizard. Administrator rights may be required on the PC to install the
software.
3. Start the "SOPAS ET" program after completing the installation. Path: Start > Pro‐
grams > SICK > SOPAS ET Engineering Tool > SOPAS.
4. Establish communication between SOPAS ET and the device with the automati‐
cally launching wizard. To do so, select the device under the devices available
depending on the connected communication interface, e.g., Ethernet. (Default Eth‐
ernet address: IP address: 192.168.0.1, subnet mask: 255.255.255.0).
SOPAS ET establishes communication with the device and loads the associated
device description file. The device project tree opens.
7 COMMISSIONING
42
O P E R A T I N G I N S T R U C T I O N S | CLV61x DualPort (PROFINET) 8017842/ZOK7/2019-02-01 | SICK
Subject to change without notice
