Status of digital outputs with output value behavior
Switching on the PROFINET network Values are initialized to “passive”
The reading cycle input can also be controlled by the fieldbus. If the fieldbus is inter‐
rupted, the reading cycle input is no longer updated. Reading results can get lost since
the reading cycle input keeps the last value from before the interruption.
After switching on the fieldbus (power-up), the reading cycle input is set to its “passive”
value.
14.6 Configuration of the device using command strings
As an alternative to the SOPAS ET configuration software, the device can also be config‐
ured, and functions can be triggered in the device, with command strings via all data
interfaces. The command strings can be displayed individually in the SOPAS ET configu‐
ration software.
NOTICE
Both the command strings and the SOPAS ET configuration software are based on a
command language that has direct access to the device command interpreter. This
command language must be used with care, as the commands sent to the device are
carried out immediately. Parameter values altered by commands are initially only active
in the current parameter set in the volatile working memory of the device. For perma‐
nent storage, the altered parameter set must be copied with a special command into
the permanent store, so that the alteration is not lost when the supply voltage is
switched off.
Command strings for triggering the read pulse:
b
START: <STX>sMN mTCgateon<ETX>
b
STOP: <STX>sMN mTCgateoff<ETX>
If the commands are entered via the terminal emulator of the SOPAS ET configuration
software, both control characters <STX> and <ETX> are omitted.
Overview of command strings for the device on request.
14.7
Abbreviations used
CAN Controlled Area Network. Field bus log based on the CAN bus
CDB Connection Device Basic (connection box)
CDM Connection Device Modular (connection module)
CLV Code reader V-principle
CMC Connection Module Cloning
ID Identification
MAC Medium Access Control
MRP Media Redundancy Protocol
PN PROFINET
SOPAS ET SICK Open Portal for Application and Systems Engineering Tool (PC
software for Windows for configuration of SICK devices)
PLC Programmable Logic Controller
SMART SICK Modular Advanced Recognition Technology
TCP/IP Transmission Control Protocol/Internet Protocol
