Housing Cast aluminum
Housing color Light blue (RAL 5012)
Front screen Glass (optionally plastic), identifier see see "Type code", page 13
Safety EN 60950-1: 2011-01
Enclosure rating IP 65 (EN 60529: 2014-09)
Protection class
Intended for operation in SELV systems (safety extra low voltage).
Weight
3)
Device with front reading window: 290.5 g
Device with side reading window: 310 g
Device with side reading window and heating: 346 g
Dimensions Device with front light emission: 61 mm x 96 mm x 38 mm
Device with side light emission: 80 mm x 96 mm x 38 mm
Conformity CE, UL
4)
1)
Service interface, for temporary use only.
2)
For switching outputs without load.
3)
With connecting cable, male connector and glass reading window.
4)
Only UL-certified if the type label contains the UL logo and the UL conditions are complied with during
device operation. For further information, see "Certification in accordance with UL60950", page 63.
12.5 Ambient data
Table 17: CLV61x Dual Port: technical data for ambient conditions
Electromagnetic compatibility
(EMC)
Radiated emission: EN 61000-6-4: 2007-01 + A1: 2011-02
Electromagnetic immunity: EN 61000-6-2: 2005-08
Vibration resistance EN 60068-2-6: 2008-02
Shock resistance EN 60068-2-27: 2009-05
Ambient operating temperature Device without heating: 0 °C ... +40 °C
Device with heating: ‒35 °C ... +40 °C
Storage temperature Device without heating: ‒20 °C ... +70 °C
Device with heating: ‒35 °C ... +70 °C
Permissible relative humidity 0% ... 90%, non-condensing
Ambient light immunity 2,000 lx, on bar code
Bar code print contrast (PCS) ≥ 60 %
12.6 Dimensional drawings
Dimensions see "Device view", page 16.
12.7 Reading fields
12.7.1 Specification diagram for reading fields
Table 18: Reading conditions for reading field diagrams
Characteristic Value
Test code Code 39/ITF
Print ratio 2:1
Print contrast > 90%
Tilt ±10°
Ambient light ≤ 2,000 lx
TECHNICAL DATA 12
