NOTE
The screws are for mounting the device on mounting equipment (bracket) supplied
by the user. The screw length depends on the mounting base (wall thickness of the
bracket). When using an optional SICK bracket, the screws for mounting the device
are included in the scope of delivery for the bracket.
■
Tool and tape measure
5.2.2 Instructions for mounting the device when the ambient temperature can fall below 0 °C
NOTE
For the electrical installation procedure, see "Instructions for electrical installation when
the ambient temperature can fall below 0 °C", page 33
The devices with integrated heating (CLV61x-DxxxxxF0) can be operated at low ambient
temperatures down to –35 °C.
Prerequisites:
•
Only perform mounting and connection work at ambient temperatures between
–25 °C and 40 °C.
•
The device may only be in a non-operating state at ambient temperatures below
0 °C.
•
During mounting, make sure that heat transfer between the device and the sur‐
rounding environment is kept as small as possible. Use appropriate holders
(optional accessories).
NOTICE
Operating the device at the lower limit of the permissible ambient temperature range
The ensure that the device can produce the required heating power, do not expose it to
strong air flows (e.g. from a ventilation system).
b
If necessary, take appropriate measures to shield the device from air flows.
NOTICE
If the ambient temperature is below 0 °C, please note:
•
The black rubber cover fitted at the side over the corner must be flush with the
device.
•
Do not move the swivel connector on the device.
5.2.3 Mounting device
The device is mounted on the bracket using at least two M5 blind hole threads that are
in pairs on both of the narrow sides of the device, see "Device view", page 16.
The device can be installed using optional SICK brackets or customer-specific brackets.
SICK offers prefabricated brackets which are optimally suited for the mounting of the
device in a wide range of applications. See:
•
www.sick.com/CLV61x_Dual_Port
Example: The design of the bracket and adapter plate supports many different installa‐
tion variants, for example, as well as the alignment of the device on two axes.
MOUNTING 5
8017842/ZOK7/2019-02-01 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x DualPort (PROFINET)
27
Subject to change without notice
