Figure 9: Example mounting of a device with bow-shaped mounting bracket (SICK accessories,
illustration of the device can differ)
Devices with heating
NOTE
Three plastic insulation panes are to be used across from the bracket for heat insula‐
tion on devices with heating. These panes are included with the mounting brackets for
thermal decoupling (SICK accessories).
Figure 10: Example mountings of a device with external heating using bow-shaped mounting
brackets (SICK accessories). Illustration of the device may differ.
1
Plastic insulation panes
User-supplied brackets
The brackets should meet the following requirements:
■
Stable mounting device
5 MOUNTING
28
