(19)
(3.5)
10
11
4
38
10
48
16
22
10
19
(M5)
(Ø 7.5)
5
4
4
5
2
1
6
7
3
Figure 32: View of the quick release (dimensions in mm) and combination with mounting bracket
1
Width across flats, size 3
2
M5 thread hole, screw-in depth max. 8 mm
3
Quick release (part number 2025526)
4
Quick release, part 1
5
Quick release, part 2
6
Width across flats, size 3
7
Mounting bracket (part number 2020410)
13 ACCESSORIES
62
O P E R A T I N G I N S T R U C T I O N S | CLV61x DualPort (PROFINET) 8017842/ZOK7/2019-02-01 | SICK
Subject to change without notice
