Parameter Description
Output testing Without test pulses
W
hen this option is selected, the test pulses for this output are
deactivated.
Additional measures for all safety outputs of the module may be
required, see "Safety-related parameters", page 126.
This option is required for connected devices that cannot tolerate
a brief interruption in the voltage supply (test pulses).
Test pulses allowed
W
hen this option is selected, test pulses are activated depending
on other elements on the module. If no element on the safety
outputs of the same module is configured with the Without test
pulses option, the test pulses are activated.
The report shows whether the test pulses are activated or deacti‐
vated.
This option is suitable for connected devices where the test pulses
have no effect on the connected device and they are not needed
to achieve the required safety-related characteristics.
With test pulses
W
hen this option is selected, the test pulses for this output are
activated.
This option is required for connected devices where regular test
pulses are essential for achieving the required safety-related char‐
acteristics.
"Safety-related parameters", page 126
Increased capacitive loads
allo
wed
This may be necessary for switching loads in cases where the
voltage at the load does not drop to the Low level as quickly as
expected.
Examples
•
Loads with a capacitance that is higher than the standard level
permitted for the output, such as the supply voltage of PLC
output cards that require safety-related switching.
•
Inductive loads that cause an overshoot in the positive voltage
range once the induction voltage has decayed.
Take into account the longer response time.
Further topics
•
"Discrepancy time", page 47
•
"Maximum response time", page 131
•
"Data sheet", page 126
•
"Report main navigation menu", page 112
7.4.7 Adding, configuring and expanding elements
7.4.7.1 Adding elements
Overview
T
he Catalog shows under Elements all of the devices (e.g., sensors, actuators, encoders)
that can be connected to the inputs and outputs of the safety controller.
Approach
1. In the Navigation pane, click on Hardware configuration.
2. Drag an element from the Catalog into the workspace but do not release it.
✓
All suitable and free inputs and outputs are highlighted.
3. Drag the element to the desired free input or output and release it.
✓
The element is connected to the relevant input or output.
7 C
ONFIGURATION
50
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
