Characteristic Value Description
R/W 1 Read
O/N 1 Offset
D/I 1 Indirect
LEN 1 2 bytes
ADD Variable Calling node
OFF ADD Variable Ordinal number of the linked node
The value stored in OFF ADD shows the ordinal number of the linked node, the
resource identification of which should be returned. The ordinal number is given in the
following list of all resources.
The result of this "long message" transaction is the resource index (RID) of the resource
requested.
The resources data is described in detail in the resources list (see chapter 8.1.3).
8.1.3 Direct access
The defining values of a resource can be read from the DSL encoder by direct access
(see chapter 7.5.2).
These defining values consist of a readable description of the resource (max. 8 charac‐
ters), the data length, the access rights, a value for time overrun and the data type of
the resource.
The desired value is selected by the user by setting a corresponding offset address.
Please note that for different encoders the time overrun values can be different. There‐
fore it is recommended to check the time overrun values prior to reading. The values
provided in the resources list are only examples.
table 45 below sets out all possible access methods (direct and indirect) and their
associated values.
Table 45: Different methods of resource access
Resource type
(see chapter 8.2)
Access Offset
address
Data Note
Node Direct read‐
ing
0/none Resource name e.g. "ROOT"
1 Resource data length e.g. 05h for 5 Sub-
entries
2 Read access level e.g. 0 for access level
0
3 Write access level e.g. 2 for access level
2
4 Time overrun e.g. 46h for 70 ms
5 Data type 00h for node indica‐
tor
Indirect read‐
ing
0 Number of linked
nodes
e.g. 5
1 RID of the 1st linked
node
e.g. 001h
…
