1
1
2
3
1
Mounting screw, M5 hexagon socket screw
2
Alignment bracket
3
Star grip screw
2. Unscrew the star grip screw.
3. Insert the distance sensor into the alignment bracket.
Set
Esc
<
<
4
3
2
4
Distance sensor
4. Secure the distance sensor using the star grip screw.
5. Secure the star grip screw in place using a knurled nut.
Set
Esc
<
<
5
4
5
Knurled nut
5 MOUNTING
