Table 12: More? menu
Options Description
Yes / No Activate or deactivate advanced menu view The entire menu is displayed
when activated. When deactivated, all parameters in Menu are hidden
except for the PROFINET station name StName.
Options
•
Yes
•
No
Factory setting
•
No
7.1.7 MFx On menu
In this menu, you can activate or deactivate multifunctional input/output MF1 and
multifunctional output MF2.
Requirement for display
More? menu: Yes option.
Table 13: MFx On menu
Options Description
Enable / Disable Activate or deactivate MF1 and MF2.
Options
•
Enable: MF1 and MF2 are activated in the hardware.
•
Disable: MF1 and MF2 are deactivated in the hardware and are therefore
hidden in the menu.
Factory setting
•
Enable
7.1.8 MF1 menu
You can parameterize multifunctional input/output MF1 using this menu.
Requirement for display:
•
more? menu: Yes option
•
Menu MFx On: Enable option
Table 14: MF1 menu
Parameter Description
ActSta Select the active level or signal edge of the MF1.
Options
•
ActLow: LOW level output with active output (safety criterion fulfilled) or
activation of input at falling signal edge
•
ActHi: HIGH level output with active output (safety criterion fulfilled) or
activation of input at rising signal edge
Factory setting
•
ActLow
OPERATION 7
