Parameter Description
Functn Select MF1 function.
Options
•
Dist: MF1 is used as a distance switch output.
•
Speed: MF1 is used as a speed switch output.
•
Srvice: MF1 is used as a service output.
•
LsrOff: MF1 is used as an input for switching off the laser.
•
Preset: MF1 is used as an input for activating the static preset.
Factory setting
•
Dist
The corresponding menu is displayed depending on the function selected for
the Functn parameter. See the relevant table for the parameter description.
Count Counts the switching events of the MF1. You can reset the counter by
switching the device off and on again.
7.1.9 MF1 – Dist submenu
In this submenu, you can configure the MF1 as a distance switch output.
Requirement for display:
■
more? menu: Yes option
■
Menu MFx On: Enable option
■
Functn parameter: Dist option
7 OPERATION
38
