SICK PROFINET DL100 Pro - Module 23: Setup Offset; Module 25: Setup Special Functions

Module parameters
Name Description
Distance Preset Static
[mm]
Define the distance preset value.
Options
•
-300,000 ... 300,000 [mm]
Factory setting
•
0 [mm]
10.3.12 Module 23: Setup Offset
Type
Configuration module, no input and output data
Description
This module is used to set the offset.
NOTE
If a preset is triggered via module 5 Distance/i2w, Preset Dyn./o2w or digital input MF1,
the offset value specified via module 23 is overwritten by the offset value calculated
during the preset.
Module parameters
Name Description
Distance Offset [mm] Specify the offset. The offset is added to the internally determined dis‐
tance value. The offset is applied to all outputs and to what is shown on
the distance display.
Triggering a preset overwrites the offset. The following applies: Offset =
Preset - measured distance value.
Options
•
–600,000 … +300,000 [mm]
Factory setting
•
0 [mm]
10.3.13 Module 25: Setup Special Functions
Type
Configuration module, no input and output data
Description
This module can be used to set the filter characteristic for the measured distance
values, the filter depth for the measured speed values, the measurement direction, the
time for maximum error suppression, the temperature threshold for switching on the
heater, and the laser transmission frequency.
