Warehouse ambient tem‐
perature range
-40 … +75 °C
Relative humidity Max 95% (non-condensing)
Enclosure rating IP 65
Effect of air pressure 0.3 ppm/hPa
Effect of temperature 1 ppm/K
Temperature drift Typically 0.1 mm/K
Maximum traversing speed 15 m/s
Maximum acceleration 15 m/s²
Mechanical strength EN 60068-2-27 (Ea): Continuous shock: 25 g / 6 ms, half sine, 6
axes, 500 shocks per axis
EN 60068-2-27 (Ea): Shock: 30 g / 6 ms, half sine, 6 axes, 3
shocks per axis
EN 60068-2-64 (Fh): Broadband noise vibrations: 10 g rms, 10…
500 Hz, 6 axes, 2 h per axis
1)
The device may cause interference if used in a residential environment.
2)
A warm-up phase until activation of the laser diode is required for temperatures under –10 °C; typical
duration at –20 °C: 20 min at 24 V.
3)
For operation below –20 °C, a supply voltage of at least 24 V is required. A warm-up phase up until
activation of the laser diode is required for temperatures under –10 °C: typical duration at –40 °C:
35 min at 24 V.
4)
Maximum 95% humidity, non condensing
13.8 Structural design
Table 45: Structural design
Dimensions see "Dimensional drawing", page 89
Weight
■
Device: approx. 800 g
■
Alignment bracket (optional): approx. 800 g
Materials
■
Housing: Cast aluminum GD-AlSi12Cu1 (3.2982.05)
■
Viewing window: PMMA
Connections
•
M12, SpeedCon™-compatible
Display
■
6-digit with a 5 x 7 dot matrix
