SICK PROFINET DL100 Pro - Module 13: Temp;I1 B, Level;I2 B, Hrs;I2 B; Module 20: Setup Mfx

Rel. Adr. Description
1.0
•
Bit = 1: Switch off laser
•
Bit = 0: Switch on laser
Type
•
1 bit
1.1 ... 1.7 Reserved
Type
•
1 bit
10.3.9 Module 13: Temp/i1b, Level/i2b, Hrs/i2b
Type
Input module, 5 bytes, consistent
Description
The diagnostic data of the device can be read using this module.
Input values
Rel. Adr. Description
0 Device temperature [°C]
Type
•
Signed 8-bit number in two´s complement
1 Signal attenuation [dB] see "Received signal level", page 28.
Type
•
Signed 16-bit number in two´s complement
3 Operating hours in units of 10 hours.
Type
•
Signed 16-bit number in two´s complement
10.3.10 Module 20: Setup MFx
Type
Configuration module, no input and output data
Description
This module defines the behavior of the switchable MF1 input and output.
Table 29: Module parameters for Setup MFx
Name Description
MFx Activate or deactivate MF1 and MF2.
Options
•
enable
•
Disable
Factory setting
•
enable
