Table 30: MF1 module parameter
Name Description
Function MF1 Select function for MF1 input and output.
Options
•
[Output] Distance Threshold: Output is switched when the distance has
been overwritten from the module parameter [MF1 Distance] threshold.
•
[Output] Speed Threshold: Output switches when the speed limit from
the [MF1 Speed] Threshold module parameter has been exceeded. The
direction is set in the [MF1 Speed] Mode module parameter.
•
[Output] Service: The output switches if at least one of the service bits
selected under [MF1 Service] Laser Warning...[MF1 Service] Heating has
been set.
•
[Input] Laser Off: Measurement laser is deactivated via the input.
•
[Input] Preset Static: "Preset Static” function activated via the input.
Factory setting
•
[Output] Distance Threshold
[MF1] Active State Select active level or signal edge of MF1
Options
•
low
•
High
Factory setting
•
low
[MF1 Distance] Thresh‐
old [mm]
Enter the distance threshold value.
Options
•
-300,000 ... 300,000 [mm]
Factory setting
•
1,990 [mm]
[MF1 Distance] Hyste‐
resis [mm]
Enter the distance threshold hysteresis see "MF1 – Dist submenu",
page 38.
Options
•
1 ... 300,000 [mm]
Factory setting
•
10 [mm]
[MF1 Speed] Threshold
[mm/s]
Enter speed threshold. The switching hysteresis is fixed at 100 mm/s.
Options
•
0 ... 15,000 [mm/s]
Factory setting
•
5,000 [mm/s]
[MF1 Speed] Mode Select direction for detecting the speed overrun.
Options
•
negative direction [-]
•
positive direction [+]
•
both directions [+/-]
Factory setting
•
both directions [+/-]
