10.2.2 Module overview
Module category “01_Measurements”
Table 25: Module overview – “01_Measurements”
Module number Total size Module type Contents
Designation Type Size
1 2 words Input module Distance Input 2 words
2 1 word Input module Distance Input 1 word
3 2 words Input module Speed Input 2 words
4 4 words Input module Distance Input 2 words
Speed Input 2 words
5 2 words Input and out‐
put module
Distance Input 2 words
Preset Dyn. Output Bit 0 ... 29
Delete Preset Output Bit 30
Activate Preset Output Bit 31
6 6 words Input module Time stamp Input 4 words
Distance Input 2 words
7 8 words Input module Time stamp Input 4 words
Distance Input 2 words
Speed Input 2 words
Module category “02_Device Status”
Table 26: Module overview – “02_Device Status”
Module number Total size Module type Contents
Designation Type Size
10 2 bytes Input and out‐
put module
Status Input 16 bit
Control (Laser Off) Output 16 bit
13 5 bytes Input module Temperature [°C] Input 1 byte
Signal level [dB] Input 2 bytes
Service hours [10 h] Input 2 bytes
