Module category “03_Device Setup”
Table 27: Module overview – “03_Device Setup”
Module number Total size Module type Contents
Designation Type Value range
20 Empty Parameter mod‐
ule
MFx Parameter enable / disable
Function MF1 Parameter see "Module
20: Setup MFx",
page 68
[MF1] Active State Parameter high / low
[MF1 Distance] Thresh‐
old [mm]
Parameter –300,000 ...
300,000
[MF1 Distance] Hyste‐
resis [mm]
Parameter 1 ... 300,000
[MF1 Speed] Threshold
[mm/s]
Parameter 50 ... 15,000
[MF1 Speed] Mode Parameter [+], [–], [+/–]
[MF1 Service] Laser
Warning
Parameter off/on
[MF1 Service] Level
Warning
Parameter off/on
[MF1 Service] Temp.
Warning
Parameter off/on
[MF1 Service] Plausib.
Warning
Parameter off/on
[MF1 Service] Not
Ready
Parameter off/on
[MF1 Service] Heating
Status
Parameter off/on
Function MF2 Parameter see "Module
20: Setup MFx",
page 68
[MF2] Active State Parameter high / low
[MF2 Distance] Thresh‐
old [mm]
Parameter –300,000 ...
300,000
[MF2 Distance] Hyste‐
resis [mm]
Parameter 1 ... 300,000
[MF2 Speed] Threshold
[mm/s]
Parameter 50 ... 15,000
[MF2 Speed] Mode Parameter [+], [–], [+/–]
[MF2 Service] Laser
Warning
Parameter off/on
[MF2 Service] Level
Warning
Parameter off/on
[MF2 Service] Temp.
Warning
Parameter off/on
[MF2 Service] Plausib.
Warning
Parameter off/on
[MF2 Service] Not
Ready
Parameter off/on
[MF2 Service] Heating
Status
Parameter off/on
