3. Trigger the Preset function via bit 31 of the output values.
4. The output value of the device corresponds at the initialization position to the
initialization value from bits 0 to 29.
NOTE
By setting bit 30 in the 5 Distance/i2w, Preset Dyn/o2w, module, the preset value and
offset value are reset to the factory setting 0 mm. This is independent of whether a
static preset was previously triggered via MF1 or a dynamic preset via module 5.
10 PROFINET IO INTERFACE
80
O P E R A T I N G I N S T R U C T I O N S | DL100 Pro PROFINET 8015069/19H9/2021-10-15 | SICK
Subject to change without notice
