Chapter 9 Operating instructions
Flexi Classic
92 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011509/YPP0/2015-10-26
Subject to change without notice
Configuration
9 Configuration
Check the configuration for the protective device after every change!
If you change the configuration, you must check the effectiveness of the protective device.
Please observe the test notes in the operating instructions of the connected protective
device.
To configure the Flexi Classic you will need:
a screwdriver
9.1 Accepting the system configuration
= Switch off the voltage supply (terminals A1, A2) at all the main modules.
= Use a screwdriver to set the desired switch positions (programs and functions) at the
rotary switches of all the modules of the system.
= Set the control functions at all the modules of the system by external connecting of the
terminals S1, S2 and S3.
= Switch on the voltage supply of all the modules while keeping the ENTER button of the
main module UE410-MU or UE410-GU pressed.
Do not actuate any of the RESET buttons connected when in this state!
= When the ERR indicator begins to flash, release the ENTER button within 3 seconds.
The selected operating mode is stored in non-volatile memory and is active.
If the ENTER button is pressed for more than 3 seconds, the entire system switches to the
error state. The ERR indicator flashes.
Please refer to the description in section 10.4 “Error indications of the ERR error LED” on
page 94.
All later changes at the connection of S1, S2 and S3 will cause a lock-out (ERR).
