Page #107 background image
Operating instructions Chapter 11
Flexi Classic
8011509/YPP0/2015-10-26 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 107
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Safety specific characteristics
All these data are based on an ambient temperature of +40 °C.
Safety integrity level
31)
SIL3 (IEC 61 508)
SIL claim limit
31)
SILCL3 (EN 62 061)
Category Category 4 (EN ISO 13 849-1)
Performance Level
31)
PL e (EN ISO 13 849-1)
T
M
(mission time) 20 years (EN ISO 13 849-1)
PFD 5.8 × 10
–6
PFHd (1/h) 3.8 × 10
–9
SFF 96 %
DC 99 %
Single-channel
input, single-
channel output
Single-channel
input, dual-
channel output
Dual-channel
input, single-
channel output
Dual-channel
input, dual-
channel output
PFD () 2.4 × 10
–5
7.0 × 10
–6
2.3 × 10
–5
5.8 × 10
–6
% of SIL3 2.4 % 0.7 % 2.3 % 0.6 %
PFHd (1/h) 7.3 × 10
–9
3.8 × 10
–9
7.3 × 10
–9
3.8 × 10
–9
% of SIL3 7.3 % 3.8 % 7.3 % 3.8 %
11.1.4 UE410-2RO/UE410-4RO output modules
Minimum Typical Maximum
Supply circuit (via UE410-MU)
Power consumption
UE410-4RO 3.2 W
UE410-2RO 1.6 W
Input circuit B1, B2
Input voltage 18 V DC 30 V DC
Output circuit (13/14, 23/24, 33/34, 43/44)
Number of N/O contacts
UE410-2RO 2
UE410-4RO 4
Number of N/C contacts
UE410-2RO 1
UE410-4RO 2
31)
For detailed information on the safety design of your machine/system, please contact your local SICK
representative.
Tab.
44
:
PFD and PFHd
values for UE410-8DI
Tab.
45
:
Data sheet
UE410-2RO/UE410-4R0
