Commissioning
30 © SICK AG • Subject to change without notice • 8014865/ZUJ3/2018-11-29
Filter parameters
Filter type (F) Filter strength (P) Plausibility check Holding time
overxcycles
Preferred distance
level
Averaging
overxcycles
F00 – No No No No
F01 0 (factory setting) Yes 4 Near sensor No
1 Yes 8 Near sensor No
2 Yes 12 Near sensor No
3 Yes 16 Near sensor No
4 Yes 20 Near sensor No
5 Yes 50 Near sensor No
6 Yes 100 Near sensor No
7 Yes 200 Near sensor No
8 Yes 500 Near sensor No
9 Yes 1000 Near sensor No
F02 0 Yes 4 Near sensor 2
1 (factory setting) Yes 4 Near sensor 4
2 Yes 8 Near sensor 6
3 Yes 8 Near sensor 8
4 Yes 8 Near sensor 10
5 Yes 8 Near sensor 20
6 Yes 8 Near sensor 32
7 Yes 8 Near sensor 64
8 Yes 8 Near sensor 128
9 Yes 8 Near sensor 255
F03 0 Yes 4 Near sensor 1
1 Yes 8 Near sensor 2
2 Yes 12 Near sensor 3
3 Yes 16 Near sensor 4
4 Yes 20 Near sensor 8
5 Yes 50 Near sensor 16
6 Yes 100 Near sensor 32
7 Yes 200 Near sensor 64
8 Yes 500 Near sensor 128
9 Yes 1000 Near sensor 255
F04 0 Ja 4 Away from sensor 1
1 Ja 8 Away from sensor 2
2 Ja 12 Away from sensor 3
3 Ja 16 Away from sensor 4
4 Ja 20 Away from sensor 8
5 Ja 50 Away from sensor 16
6 Ja 100 Away from sensor 32
7 Ja 200 Away from sensor 64
8 Ja 500 Away from sensor 128
9 Ja 1000 Away from sensor 255
Table 7: Filter parameters
